Specifications
Product Name | Plastick Film Faced Plywood/Construction Formwork Plywood. |
Production Application | Construction, Truck/Container Flooring, Packing, etc. |
Size | 600x1000mm, 610x2440mm, 1220x2440mm, 915x2135mm, etc. |
Thickness | 2/2.5/3.0/3.6/4.0/5.2/6/8/9/10/12/15/18/20/21/25mm |
Glue | MR, E1, E2, Melamine, WBP Phenolic, etc, |
Core Material | Full poplar, full eucalyptys, full birch, bamboo, mixed hardwood, etc. |
Color of Film | Green, Yellow, Blue, Red, Brown, Black, Customize colors. |
Density of Film | 135G/M2, 150G/M2,180G/M2, 220G/M2, 240G/M2 |
Finish of Film | Mirror, high glossy, Matte, wire-mesh, anti-slip, etc. |
Moisture Content | 8%--12% |
Edge Processing | Paint with waterproof acrylic varnish. |
Hot Press | One or two times hot press. |
Time of Usage | 30-50 Times (Depends on the quality grades) |
Thickenss Tolerance | Less than 6mm, ±0.2-0.3mm More than 10mm, ±0.5mm |
Payment Terms | 1. Irrevocable L/C at sight 2. 30% T/T as deposit, the 70% balance to be paid against the copy of B/L |
Delivery Time | 10-20 days upon the receipt of 30% T/T deposit or L/C at sight |
MOQ | 1*20'GP Container |
Supply Ability | 30.000 CBM per month. |
Performance
1. If put in boiling water for 48 hours, it is still glue-sticking and non-deformed.
2. Physical mood is better than iron moulds and can satisfy the requirements of constructing mould.
3. Solves the problems of leaking and rough surface during constructing process.
4. Particularly suitable for watering concrete project because it can make the concrete surface smooth and flat.
5. Realizing a higher economic profits.
Board Density | >530KGS/M3 (Poplar Core) |
>630KGS/M3(Mixed Hardwood Core) | |
>700KGS(Birch Core) | |
>700KGS(Bamboo Core) | |
Moisture | ≤9% |
Bonding Strength | ≥0.7MPa |
Abrasion | ≤0.1G.100R |
Impulsion | 40KJ/M2 |
Modulus of Elasticity | ≥5000MPa |
Bending Strength | ≥40MPa |
Warp Degree | ≤1% |
Thickness Tolerance | ±0.5MM |
Thickness Expansion Rate | ≤8% |
Specifications
Product Name | Plastick Film Faced Plywood/Construction Formwork Plywood. |
Production Application | Construction, Truck/Container Flooring, Packing, etc. |
Size | 600x1000mm, 610x2440mm, 1220x2440mm, 915x2135mm, etc. |
Thickness | 2/2.5/3.0/3.6/4.0/5.2/6/8/9/10/12/15/18/20/21/25mm |
Glue | MR, E1, E2, Melamine, WBP Phenolic, etc, |
Core Material | Full poplar, full eucalyptys, full birch, bamboo, mixed hardwood, etc. |
Color of Film | Green, Yellow, Blue, Red, Brown, Black, Customize colors. |
Density of Film | 135G/M2, 150G/M2,180G/M2, 220G/M2, 240G/M2 |
Finish of Film | Mirror, high glossy, Matte, wire-mesh, anti-slip, etc. |
Moisture Content | 8%--12% |
Edge Processing | Paint with waterproof acrylic varnish. |
Hot Press | One or two times hot press. |
Time of Usage | 30-50 Times (Depends on the quality grades) |
Thickenss Tolerance | Less than 6mm, ±0.2-0.3mm More than 10mm, ±0.5mm |
Payment Terms | 1. Irrevocable L/C at sight 2. 30% T/T as deposit, the 70% balance to be paid against the copy of B/L |
Delivery Time | 10-20 days upon the receipt of 30% T/T deposit or L/C at sight |
MOQ | 1*20'GP Container |
Supply Ability | 30.000 CBM per month. |
Performance
1. If put in boiling water for 48 hours, it is still glue-sticking and non-deformed.
2. Physical mood is better than iron moulds and can satisfy the requirements of constructing mould.
3. Solves the problems of leaking and rough surface during constructing process.
4. Particularly suitable for watering concrete project because it can make the concrete surface smooth and flat.
5. Realizing a higher economic profits.
Board Density | >530KGS/M3 (Poplar Core) |
>630KGS/M3(Mixed Hardwood Core) | |
>700KGS(Birch Core) | |
>700KGS(Bamboo Core) | |
Moisture | ≤9% |
Bonding Strength | ≥0.7MPa |
Abrasion | ≤0.1G.100R |
Impulsion | 40KJ/M2 |
Modulus of Elasticity | ≥5000MPa |
Bending Strength | ≥40MPa |
Warp Degree | ≤1% |
Thickness Tolerance | ±0.5MM |
Thickness Expansion Rate | ≤8% |
Inner covered by plastic bags, outer covered by thick panels( plywood, MDF, cartons), then fastened by steel belts with pallets. Suitable to seaworthy transportation.
Package/Container | Loading Quantity |
Loose Packing in 20'GP container | 26 CBM |
FCL in 20'GP with Pallets | 8 Pallets, 22CBM |
FCL in 40'GP with Pallets | 16 Pallets, 43CBM |
Others | According to the size and thickness |
Related Products
Inner covered by plastic bags, outer covered by thick panels( plywood, MDF, cartons), then fastened by steel belts with pallets. Suitable to seaworthy transportation.
Package/Container | Loading Quantity |
Loose Packing in 20'GP container | 26 CBM |
FCL in 20'GP with Pallets | 8 Pallets, 22CBM |
FCL in 40'GP with Pallets | 16 Pallets, 43CBM |
Others | According to the size and thickness |
Related Products
Company Introduction
Hunglin Wood factory is wood-based panel products company serving the industrial and building materials markets.
Our main products are plywood, MDF, PVC edge banding/lipping, melamined board, etc.
Our company was established in 2015, and we have many years of experience in the wood industry.
Through the efforts of the whole company, we have become a strong wood manufacturer continuously working toward improving product quality.
We have always focused on research, development and innovation.
We believes in reasonable prices, efficient production time and good after-sales service.
We hope to cooperate with more customers in the future and welcome all potential buyers to contact us.
Our Service
1. All inquires will be replied with 24 hours;
2. Sample charge will be REFUNDED after you placed the big order;
3. Strictly Quality Control by Professional QC Team;
4. Factory Direct Competitive Price, One Stop Service, OEM Service Offered;
5. Various Designs, Sizes & Colors are available;
6. Selected High Quality Raw Material, Aesthetic appearance, High-End finishes;
7. We can supplied EXW,FOB,CIF,DDU shipping terms;
8. We give Customer Service Supervisor within 3 months;
9.Guaranteed after-sell service ,can call our office or our factory whenever there is any problem.
FAQ
Q: Are you a factory or trading company?
A: We are professional manufacturer, and we have more than 10 years for exporting and wood product's experiences.
Q: Where is your company located?
A: Our company is located in Weifang city, Shandong province, China.
1.5 hour from Qingdao Liuting International Airport.
2 hours from Shanghai Pudong International Airport.
2.5 hours from Guangzhou Baiyun International Airport.
Q: Do you have MOQ request?
A: Our MOQ is usually 20ft container.
Q: What is your delivery time?
A: The delivery time is 15-20days after received your deposit.
Q: What is the delivery port?
A: Qingdao, Lianyungang.
Q: Do the samples are available?
A: Yes, the sample is free and express charge would be collected in your side or supply us your express account NO.
And after the order is confirmed, this charge could be returned from the order.
Q: May I visit your factory for inspection before placing the order.
A: You are warmly welcome to visit our factory anytime. Please let us know your
schedule in advance so that we can book hotel and arrange pickup for you.
